General Description
● SLE0504/SLE0503 are surge rated diode arrays  designed to protect high speed data interfaces. This  series has been specifically designed to protect sensitive components which are connected to data  and transmission lines from overvoltage caused by  ESD (electrostatic discharge), CDE (Cable Discharge Events), and EFT (electrical fast transients).

● The unique design incorporates surge rated, low  capacitance steering diodes and a TVS diode in a  single package. During transient conditions, the steering diodes direct the transient to either the  positive side of the power supply line or to ground.  The internal TVS diode prevents over-voltage on the power line, protecting any downstream components.

● The low capacitance array configuration allows the  user to protect four high-speed data or transmission  lines. The low inductance construction minimizes voltage overshoot during high current surges.

Features
● Array of surge rated diodes with internal TVS Diode
● Small package (2.4 x 2.2mm) saves board space
● Protects up to four I/O lines & power line
● Low capacitance (<1pF) for high-speed interfaces
● No insertion loss to 2.0GHz
● Low leakage current and clamping voltage
● Low operating voltage: 5.0V/3.3V
● Solid-state silicon-avalanche technology

Applications
● USB 2.0
● USB OTG
● Monitors and Flat Panel Displays
● Digital Visual Interface (DVI)
● High-Definition Multimedia Interface (HDMI)
● Gigabit Ethernet
● SIM Ports
● IEEE 1394 Firewire Ports
