Low Capacitance Bidirectional TVS/ESD Protection Diode

Our advantages
Chinese manufacturing processes have undergone years of iteration, resulting in mature and reliable technologies. Many international corporations opt for production outsourcing in China.  As an electronic components manufacturer in China, our products can fully replace those of major international brands in 99% of applications without the need for testing verification. Our products boast high consistency in quality, reasonable pricing, ample inventory, flexible supply, short lead times, and professional after-sales service.

Slkor alternative equivalents to NXP.

Description
The SLESD0501CM is designed to protect voltage  sensitive component from ESD and transient  voltage events. Excellent clamping capability, low  leakage, and fast response time, make these  parts ideal for ESD protection on designs where  board space is at a premium. Because of its small  size, it is suited for use in cellular phones,  portable devices, digital cameras, power supplies  and many other portable applications where  board space comes at a premium. Also because  of its low capacitance, it is suited for use in high  frequency designs such as high speed line  application.  This device has been specifically designed to  protect sensitive components which are  connected to data and transmission lines from  overvoltage caused by ESD (electrostatic  discharge), and EFT (electrical fast transients).

Features

● ESD per IEC 61000-4-2 ±30 kV (Contact)
● ESD per IEC 61000-4-2 ±30 kV (Air)
● IEC61000-4-4 (EFT) 40A (5/50ηs)
● Peak power dissipation: 400W (8/20μs)
● Protects one Vcc or data line
● Low clamping voltage
● Working voltages : 4.5V
● Low leakage current
● Low capacitance

Applications

● Cell Phone Handsets and Accessories
● Microprocessor based equipment
● Personal Digital Assistants (PDA’s)
● Notebooks, Desktops, and Servers
● Portable Instrumentation
● Networking and Telecom
● Serial and Parallel Ports  Peripherals
