Slkor alternative equivalents to Texas Instruments.

24V 4A sourcing current and sinking current Dual

Description
The SL27523/4/5 are dual 4A high-speed low-side  gate drivers, MOSFETs and IGBTs can be driven  efficiently and safely. low propagation delay late  and mismatch, as well as the compact SOP-8  package, make the switching frequency of  MOSFETs can reach hundreds of kHz. this chip Ideal for synchronous rectification drives for  server and communication power supplies, in this  case, the dead time of the synchronous MOSFET  directly affects the transformer. Converter efficiency. The driver can increase the output  through the parallel connection of two channels. Out the drive current. Input pin threshold voltages  are based on TTL levels and-5V to 20V input.  Wide range of VDD supply voltages from 4.5V to  20V to efficiently drive MOSFET or GaN power  devices. Integrated UVLO protection. It is  guaranteed to keep the output low under abnormal  conditions.  The -5V to 24V independent input pin voltage range effectively ensures that Stable operation with  overshoot due to parasitic inductance. Input the  voltage threshold of the pin is also compatible with  TTL level input.

Features

● Dual-channel independent-grid driving
● 4A peak sourcing current and sinking current
● V_DD power supply with wide ranges as high as 25V
● Independent enabling input ? Dual channels can be used in parallel for high current drive
● Inverting and non-inverting inputs optional
● V_DD under-voltage protection
● Compatible with TTL and CMOS input levels
● Low propagation delay
● 1ns typical delay matching between two channels
● When the input is floating, the output is low
● -40oC to 125oC operating temperature range

Applications
● AC/DC and DC/DC converter
● Server and rectifier for communication equipment
● EV/HEV inverter and DC/DC converter
● PV voltage rise and inverter
● UPS
● Motor control
● For Emerging Wide Bandgap Power Device Drivers
